Typical SPV Application: Truck Mounted JettingMachines, Sewage Cleaning Machines etc.
Recommended up to 60 HP Truck Chassis
Driveline Throughput Torque: 2,218 NM, 226 Kg-m
PTO Aux. Output Torque: 639 NM, 65 Kg-m (Both Front& Rear)
Gear Ratio 1:1.00 (Other Gear Ratios Availableon Demand)
No. Of Shifters: Single Mechanical Shifter withMechanical Control Linkage
Main Body: Graded CI
Full Forged 5 Bearing Single Bearing HousingDriveline (Standard Duty)
PTO Aux. Outputs (Also available with Dual In-linePTO & Direct Hydraulic Mounting)
Big & Wide Bottom Cover for Easy Maintenance(FVG: Full View Gearbox)
ILS: In-Line Mechanical & Pneumatic Shifting
COG: Choice of Gears (Spur/Helical/Shaved/Grinded)
COB: Choice of Body (FE Cast Iron/Aluminium/MSAnnealed/Hybrid)
OSS: Outside Shifter (Locking) Screw
Oil Level Indicator, Oil Filling Air Breather,Magnetic Oil Drain Plug, Double Lip Oil seals
Forced Oil Lubrication Available on Demand
External Oil Cooler & Internal Oil FilterAvailable on Demand
(PTO Hydraulic Cover with Mechanical shifter)
(PTO Hydraulic Cover with Pneumatic shifter)
(Dual in Line PTO)
VAS Unique Design Feature:After engaging or disengaging shifters, constant pneumatic air pressure is notrequired in VAS Gearboxes as a separate ball spring assembly is installed inthe shifter assembly to LOCK the shifter shafts after shifting. Pneumatic airpressure is only required to shift (engage or disengage) the shifter shafts,after shifting, pneumatic air pressure can be removed.
PTO Gearbox Operation: Both Driveline throughput (vehicle in motion) and PTO Aux. Applications cannot be engaged (operated) at the same time. Either the vehicle shall run on the road (Driveline) or in a stationary position the PTO Auxiliary Outputs can be engaged. This VAS Unique feature eliminates the possibility of an auxiliary application accident while vehicle is in motion. If Both Driveline and PTO Aux. applications are required (to be operated) simultaneously, kindly refer to our Combination Reduction models CR4, CR7 & CR8 series gearboxes which have both driveline & PTO Aux. simultaneous options with Reduction Driveline feature.
